Detajet e Produktit
Detajet e Produktit
x

Model: OCBS-T214
Interface: USB
Operating Voltage: 5V
Starting Current: 380mA
Work  Current: 240mA
Standby Current: 190mA
Shock specification: 8 G r.m.s., from 10 to 500 Hz, 2 hours per axis, 3 axes
Sensor: Overall exposure CMOS sensor
Light source: Warm yellow LED
Field view: 44° (H), 34°(V)
Motion tolerance: > 0.4m/S
Scan Angle  ( Pitch  ±65°@ 0°Roll and 0° Skew  | Roll 360°@ 0°Pitch and 0° Skew  |  Skew ±65°@ 0°Roll and 0° Pitch )
Symbol Contrast: 20% minimum reflective difference
Ambient Light Immunity: 0-100,000 Lux
Typical Depth of Field: Code39(5mil):0mm-120mm,Code39(13mil):0mm-240mm
QR(20mil):0mm-210mm
Alipay (QR 3*3CM): 40mm-650mm
Wechat pay(QR 2.3*2.3CM): 20mm-550mm

Decoding ability: 1D:Code128/EAN128,EAN.UCCcomposite,
                               Interleaved2of 5,RSS,Postnet,Plessey code,Code 39,Codabar,Code 93,
                               Code 11,Telepen,MSIcode,Standard 2 of 5,UPC/EAN etc
                               2D:PDF417, QR code, Matrix 2 of 5, MicroPDF417, Australian Post, Canada Post,Japan Post, MaxiCode, Codablock, Aztec, Dutch Post, TLC 39,DataMatrix, etc
Weight Gross:437g
Package: 151*142*84mm
Working temperature& humidity: 0 to 45 degrees centigrade,  10%~80%   No condensation
Storage temperature& humidity: -20 to 60 degrees centigrade , 10%~90%  No condensation
